2ton higher transmission arm wheel loader
| Unit Price: | 18000 USD |
|---|---|
| Min. Order: | 1 Bag/Bags |
| Packaging: | 1 units naked within 1 x 40HQ container. |
|---|---|
| Productivity: | 100 Units/Month |
| Brand: | Yineng |
| Transportation: | Ocean |
| Place of Origin: | Taian City, Shandong Province, China |
| Certificate: | ISO9001/ CE |
| Port: | Qingdao |
Basic Info
Model No.: YN926G
Product Description
1- FEATURES:
* YTO Diesel Engine is adopted, with strong power.
* Applying hydrodynamic transmission technology, single stage, 3 elements torque converter owns simple structure and high reliability.
* Controlled by flexible shaft, hydraulic power shift gearbox with 2 forward and 2 reverse gears makes operation easy.
* Single pump, split flow working hydraulic system makes lower consumption and excellent performance.
* Double sealed hydraulic pipeline joints with 24°awl and O ring of international standard, avoiding oil leakage;
* Load sensing fully hydraulic steering system makes operation easy.
* Air over hydraulic brake system; Caliper disc brakes.
* Working device with automatically leveling ability at high position.
*Bucket articulated points take sealed, lubricated, dust-proof layers, which owns good durability.
* Integral, luxury instrument board.
* New, luxury cabin.
|
Main specifications | * | Rated load | 1500kg |
| * | Overall weight | 6880kg | |
| * | Rated capacity | 2.0m3 (Food Bucket) | |
| * | Max. Tractive force | 62KN | |
| * | Max. Breakout force | ≥65KN | |
| * | Max. Grade ability | 30° | |
| * | Top Lifting | 4700mm | |
| * | Max. Dumping height | 4100mm | |
| * | Max. Dumping reach | 1400mm | |
| * | Overall dimension L x W x H | 7549*2060*2820mm | |
| * | Min. Turning radius | 4814mm | |
|
Engine | * | Model | Dongfeng Cummins 4BTA3.9-C100 |
| * | Type | In line, water cooled, four stroke, direct injection/Turbo charged | |
| * | No. of cylinder-bore/stoke | 4-102x120mm | |
| * | Rated power | 74kW/2200r/min | |
| * | Max. torque | 410N.m/1500rpm | |
| * | Min. Fuel-consume ratio | ≤242g/kW·h | |
| * | Fuel tank capacity | 100L | |
|
Transmission | * | Model | ZL16K |
| * | Gear shift | 2 forward, 2 reverse. Electronic control fixed shaft power shift gearbox | |
| * | Max. speed | 27km/h | |
|
Drive axle | * | Main reducing spiral | Grade 1 reduction |
| * | Decelerating mode | Planetary reduction, grade | |
| * | Wheel base | 2350mm | |
| * | Wheel tread | 1500mm | |
| * | Min. ground clearance | 320mm | |
|
Hydraulic system | * | System working pressure | 17.5MPa |
| * | Steering system pressure | 14Mpa | |
| * | Boom lifting time | 4.5+0.2s | |
| * | Total time | 8.5+0.5s | |
| * | Hyd tank capacity | 100L | |
| * | Leveling automatically | Yes | |
|
Break system | * | Service brake | Air over hydraulic disc brake on 4 wheels |
| * | Parking brake | Flexible shaft control caliper disc brake | |
|
Tyre | * | Type | 16/70-24 |
| * | Front tyre pressure | 0.3Mpa | |
| * | Rear tyre pressure | 0.3Mpa |
Founded in 1999, Shandong Yineng Heavy Industry Co., Ltd is a large-scale construction and agricultural equipment manufacturing enterprise integrating R&D, production and sales. The company has more than 400 employees, 8 senior engineers and 12 professional technicians. The products cover wheel loaders, underground mining machine, grass grabber, off-road forklift and etc, with 7 series, more than 100 models and equipment in total. Yineng has passed the ISO9001:2000 international quality management system certification and assessment of State Engineering Machinery Quality Supervision & Testing Center.
The company has been invited to participate in large-scale international exhibitions such as the Canton Fair, the Hanover Agricultural Machinery Exhibition in Germany, and the Bauma Fair for more than ten years. With first-class technical standards, top-notch manufacturing processes and personalized customization services, Yineng has established a broad customer network around the world, with customers all over Germany, Russia, Brazil, Iran, Saudi Arabia, Australia, Thailand, South Africa, etc. More than 40 Many countries and regions.
